Colnago
A gravel frameset in 5 sizes, from 430 to 550.
Frameset price, size 490
$9,248
sport · forward-biased · snappy handling
From Colnago’s own numbers for the 490, not marketing copy.
sport · forward-biased · snappy handling
From your saved height and inseam, not a height range.
Every size, straight from Colnago’s chart. Blanks are numbers Colnago doesn’t publish; we don’t fill them in.
| Measurement | |||||
|---|---|---|---|---|---|
| Stack (mm) | 523 | 543 | 563 | 583 | 603 |
| Reach (mm) | 370 | 375 | 380 | 386 | 393 |
| Stack / Reach | 1.41 | 1.45 | 1.48 | 1.51 | 1.53 |
| Head tube angle (°) | 70.6 | 71 | 71.5 | 72 | 72.5 |
| Seat tube angle (effective) (°) | 75.5 | 75 | 74.5 | 74 | 73.5 |
| Top tube (effective) (mm) | 506 | 521 | 537 | 554 | 572 |
| Chainstay (mm) | 412 | 412 | 415 | 415 | 417 |
| Wheelbase (mm) | 986 | 994 | 1005.8 | 1013.4 | 1024.5 |
| Trail (mm) | Not published | Not published | Not published | Not published | Not published |
| Standover (mm) | Not published | Not published | Not published | Not published | Not published |
Colnago’s geometry chart, read Jul 21, 2026.
| Size | Frameset weight(g) | Price(CAD) |
|---|---|---|
| 430 | 1495 | $9,248 |
| 460 | 1495 | $9,248 |
| 490 | 1495 | $9,248 |
| 520 | 1495 | $9,248 |
| 550 | 1495 | $9,248 |
Colnago hasn’t published frame bolt torques we can point to yet
