Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 51 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $8,905 | $8,905 | $8,905 | $8,905 | $8,905 | $8,905 |
| Frame kit (g) | 2270 | 2270 | 2270 | 2270 | 2270 | 2270 |
| Stack | 496 mm | 519 mm | 542 mm | 565 mm | 588 mm | 608 mm |
| Reach | 367 mm | 376 mm | 384 mm | 392 mm | 401 mm | 409 mm |
| Stack / Reach | 1.35 | 1.38 | 1.41 | 1.44 | 1.47 | 1.49 |
| Head tube angle | 71° | 72° | 73° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (effective) | 73° | 73° | 73° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 520 mm | 535 mm | 550 mm | 565 mm | 581 mm | 595 mm |
| Head tube length | 64 mm | 82 mm | 104 mm | 125 mm | 152 mm | 173 mm |
| Seat tube length | — | — | — | — | — | — |
| Bottom bracket drop | 74.5 mm | 74.5 mm | 72 mm | 72 mm | 69.5 mm | 69.5 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Front center | 579 mm | 580 mm | 581 mm | 588 mm | 604 mm | 617 mm |
| Wheelbase | 973 mm | 974 mm | 975 mm | 982 mm | 999 mm | 1013 mm |
| Fork rake (offset) | 58.5 mm | 52.5 mm | 46.5 mm | 43.5 mm | 43.5 mm | 43.5 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | 55.6 mm | 55.6 mm | 55.6 mm | 55.6 mm | 55.6 mm | 55.6 mm |
| Standover | 712 mm | 734 mm | 758 mm | 781 mm | 804 mm | 822 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
