Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 51 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $8,000 | $8,000 | $8,000 | $8,000 | $8,000 | $8,000 |
| Frame kit (g) | 1540 | 1540 | 1540 | 1540 | 1540 | 1540 |
| Stack | 496.1 mm | 520.2 mm | 544.6 mm | 567.5 mm | 590.7 mm | 610.7 mm |
| Reach | 368.7 mm | 376.5 mm | 383.3 mm | 391.1 mm | 400.3 mm | 408.3 mm |
| Stack / Reach | 1.35 | 1.38 | 1.42 | 1.45 | 1.48 | 1.50 |
| Head tube angle | 71° | 72° | 73° | 73° | 73° | 73° |
| Seat tube angle (effective) | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 506 mm | 526 mm | 545 mm | 565 mm | 581 mm | 595 mm |
| Head tube length | 89.6 mm | 109.3 mm | 132 mm | 156 mm | 182.8 mm | 203.7 mm |
| Seat tube length | 403 mm | 434 mm | 463 mm | 486 mm | 503 mm | 526 mm |
| Bottom bracket drop | 76.5 mm | 76.5 mm | 74 mm | 74 mm | 71.5 mm | 71.5 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Front center | 579.1 mm | 579.9 mm | 579.5 mm | 594.2 mm | 610.8 mm | 624.8 mm |
| Wheelbase | 976.8 mm | 977.6 mm | 978 mm | 992.8 mm | 1010.3 mm | 1024.5 mm |
| Fork rake (offset) | 57.5 mm | 51.5 mm | 45.5 mm | 45.5 mm | 45.5 mm | 45.5 mm |
| Fork axle to crown | 373 mm | 373 mm | 373 mm | 373 mm | 373 mm | 373 mm |
| Trail | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm |
| Standover | 699.7 mm | 731 mm | 757.4 mm | 779.1 mm | 803.4 mm | 822.2 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
