Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 51 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $5,999 | $5,999 | $5,999 | $5,999 | $5,999 | $5,999 |
| Frame kit (g) | 1800 | 1800 | 1800 | 1800 | 1800 | 1800 |
| Stack | 505 mm | 530 mm | 555 mm | 580 mm | 605 mm | 630 mm |
| Reach | 360 mm | 369 mm | 378 mm | 387 mm | 396 mm | 405 mm |
| Stack / Reach | 1.40 | 1.44 | 1.47 | 1.50 | 1.53 | 1.56 |
| Head tube angle | 70.5° | 71.5° | 72° | 72° | 72° | 72° |
| Seat tube angle (effective) | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 502 mm | 522 mm | 543 mm | 565 mm | 581 mm | 598 mm |
| Head tube length | 89.5 mm | 110.3 mm | 136.3 mm | 162.6 mm | 191.5 mm | 217.8 mm |
| Seat tube length | — | — | — | — | — | — |
| Bottom bracket drop | 76.5 mm | 76.5 mm | 74 mm | 74 mm | 71.5 mm | 71.5 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Front center | 580.5 mm | 582.7 mm | 592.5 mm | 609.5 mm | 627 mm | 644.1 mm |
| Wheelbase | 983.3 mm | 985.6 mm | 996.3 mm | 1013.4 mm | 1031.8 mm | 1048.9 mm |
| Fork rake (offset) | 60 mm | 54 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | 57.8 mm | 57.8 mm | 57.8 mm | 57.8 mm | 57.8 mm | 57.8 mm |
| Standover | 701 mm | 743 mm | 775 mm | 798 mm | 824 mm | 847 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
