Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 51 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $3,150 | $3,150 | $3,150 | $3,150 | $3,150 | $3,150 |
| Frame kit (g) | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 |
| Stack | 505 mm | 530 mm | 555 mm | 580 mm | 605 mm | 630 mm |
| Reach | 360 mm | 369 mm | 378 mm | 387 mm | 396 mm | 405 mm |
| Stack / Reach | 1.40 | 1.44 | 1.47 | 1.50 | 1.53 | 1.56 |
| Head tube angle | 70.5° | 71.5° | 72° | 72° | 72° | 72° |
| Seat tube angle (effective) | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 502 mm | 522 mm | 543 mm | 565 mm | 581 mm | 598 mm |
| Head tube length | 89.5 mm | 109.9 mm | 136 mm | 162.3 mm | 191.2 mm | 217.5 mm |
| Seat tube length | — | — | — | — | — | — |
| Bottom bracket drop | 76.5 mm | 76.5 mm | 74 mm | 74 mm | 71.5 mm | 71.5 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Front center | 579.4 mm | 581.7 mm | 591.5 mm | 608.5 mm | 626 mm | 643 mm |
| Wheelbase | 982.2 mm | 984.5 mm | 995.2 mm | 1012.3 mm | 1030.7 mm | 1047.8 mm |
| Fork rake (offset) | 59 mm | 53 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover | 701 mm | 741 mm | 773 mm | 796 mm | 823 mm | 847 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
