Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 51 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $7,535 | $7,535 | $7,535 | $7,535 | $7,535 | $7,535 |
| Frame kit (g) | 2290 | 2290 | 2290 | 2290 | 2290 | 2290 |
| Stack | 500 mm | 525 mm | 550 mm | 575 mm | 600 mm | 625 mm |
| Reach | 369 mm | 377 mm | 386 mm | 395 mm | 404 mm | 413 mm |
| Stack / Reach | 1.35 | 1.39 | 1.43 | 1.46 | 1.49 | 1.51 |
| Head tube angle | 70.6° | 71.1° | 71.6° | 71.6° | 71.6° | 71.6° |
| Seat tube angle (effective) | 74.1° | 73.6° | 73.1° | 72.6° | 72.6° | 72.6° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 516 mm | 531 mm | 552 mm | 574 mm | 591 mm | 607 mm |
| Head tube length | 75 mm | 99 mm | 122 mm | 148 mm | 177 mm | 203 mm |
| Seat tube length | — | — | — | — | — | — |
| Bottom bracket drop | 80 mm | 80 mm | 80 mm | 80 mm | 78 mm | 78 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 422.5 mm | 422.5 mm | 422.5 mm | 422.5 mm | 422.5 mm | 422.5 mm |
| Front center | 584 mm | 593 mm | 602 mm | 619 mm | 636 mm | 653 mm |
| Wheelbase | 993 mm | 1002 mm | 1012 mm | 1029 mm | 1047 mm | 1064 mm |
| Fork rake (offset) | 57.5 mm | 54.5 mm | 51.5 mm | 51.5 mm | 51.5 mm | 51.5 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — |
| Standover | 720 mm | 753 mm | 779 mm | 801 mm | 826 mm | 851 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
