Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 51 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $3,699 | $3,699 | $3,699 | $3,699 | $3,699 | $3,699 |
| Frame kit (g) | 1950 | 1950 | 1950 | 1950 | 1950 | 1950 |
| Stack | 505 mm | 530 mm | 555 mm | 580 mm | 605 mm | 630 mm |
| Reach | 370 mm | 379 mm | 388 mm | 397 mm | 406 mm | 415 mm |
| Stack / Reach | 1.36 | 1.40 | 1.43 | 1.46 | 1.49 | 1.52 |
| Head tube angle | 71° | 71.5° | 72° | 72° | 72° | 72° |
| Seat tube angle (effective) | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 512 mm | 532 mm | 553 mm | 575 mm | 591 mm | 608 mm |
| Head tube length | 83 mm | 107 mm | 133 mm | 159 mm | 188 mm | 214 mm |
| Seat tube length | — | — | — | — | — | — |
| Bottom bracket drop | 78.5 mm | 78.5 mm | 76 mm | 76 mm | 73.5 mm | 73.5 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Front center | 577 mm | 587 mm | 597 mm | 614 mm | 631 mm | 648 mm |
| Wheelbase | 990 mm | 999 mm | 1010 mm | 1028 mm | 1046 mm | 1063 mm |
| Fork rake (offset) | 52 mm | 49 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover | 681 mm | 704 mm | 733 mm | 757 mm | 784 mm | 808 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
