Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S | M | L | XL | |
|---|---|---|---|---|
| Price (CAD) | $6,000 | $6,000 | $6,000 | $6,000 |
| Frame kit (g) | 1830 | 1830 | 1830 | 1830 |
| Stack | 560 mm | 580 mm | 600 mm | 620 mm |
| Reach | 360 mm | 368 mm | 376 mm | 384 mm |
| Stack / Reach | 1.56 | 1.58 | 1.60 | 1.61 |
| Head tube angle | 69° | 70.5° | 71.5° | 72° |
| Seat tube angle (effective) | 73° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 509 mm | 521 mm | 536 mm | 551 mm |
| Head tube length | 111 mm | 126 mm | 143 mm | 162 mm |
| Seat tube length | 470 mm | 470 mm | 470 mm | 470 mm |
| Bottom bracket drop | 76 mm | 76 mm | 76 mm | 76 mm |
| Bottom bracket height | — | — | — | — |
| Chainstay | 437 mm | 437 mm | 437 mm | 437 mm |
| Front center | 608 mm | 608 mm | 612 mm | 621 mm |
| Wheelbase | 1033 mm | 1033 mm | 1038 mm | 1047 mm |
| Fork rake (offset) | — | — | — | — |
| Fork axle to crown | 430 mm | 430 mm | 430 mm | 430 mm |
| Trail | — | — | — | — |
| Standover | — | — | — | — |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
