Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 51 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $3,600 | $3,600 | $3,600 | $3,600 | $3,600 | $3,600 |
| Frame kit (g) | 1760 | 1760 | 1760 | 1760 | 1760 | 1760 |
| Stack | 520 mm | 542 mm | 564 mm | 584 mm | 604 mm | 632 mm |
| Reach | 351 mm | 362 mm | 373 mm | 381 mm | 388 mm | 399 mm |
| Stack / Reach | 1.48 | 1.50 | 1.51 | 1.53 | 1.56 | 1.58 |
| Head tube angle | 68.5° | 69.5° | 71° | 72° | 72.5° | 72.5° |
| Seat tube angle (effective) | 74° | 74° | 74° | 74° | 74° | 74° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 510 mm | 527 mm | 545 mm | 559 mm | 574 mm | 593 mm |
| Head tube length | — | — | — | — | — | — |
| Seat tube length | 436 mm | 463 mm | 490 mm | 518 mm | 549 mm | 576 mm |
| Bottom bracket drop | 79 mm | 79 mm | 77 mm | 77 mm | 75 mm | 75 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Front center | 597 mm | 606 mm | 602 mm | 607 mm | 616 mm | 636 mm |
| Wheelbase | — | — | — | — | — | — |
| Fork rake (offset) | — | — | — | — | — | — |
| Fork axle to crown | 375 mm | 375 mm | 375 mm | 375 mm | 375 mm | 375 mm |
| Trail | — | — | — | — | — | — |
| Standover | — | — | — | — | — | — |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
