Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Price (CAD) | $9,000 | $9,000 | $9,000 | $9,000 | $9,000 |
| Frame kit (g) | 1480 | 1480 | 1480 | 1480 | 1480 |
| Stack | 510 mm | 532 mm | 554 mm | 574 mm | 594 mm |
| Reach | 358 mm | 369 mm | 380 mm | 388 mm | 396 mm |
| Stack / Reach | 1.43 | 1.44 | 1.46 | 1.48 | 1.50 |
| Head tube angle | 71° | 71° | 72.7° | 72.7° | 72.7° |
| Seat tube angle (effective) | 72.5° | 72.5° | 72.5° | 72.5° | 72.5° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 519 mm | 537 mm | 555 mm | 569 mm | 583 mm |
| Head tube length | 117 mm | 143 mm | 159 mm | 179 mm | 203 mm |
| Seat tube length | 489 mm | 496 mm | 520 mm | 537 mm | 555 mm |
| Bottom bracket drop | 77.5 mm | 75 mm | 72.5 mm | 72.5 mm | 70 mm |
| Bottom bracket height | — | — | — | — | — |
| Chainstay | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Front center | 577 mm | 596 mm | 587 mm | 601 mm | 615 mm |
| Wheelbase | 971 mm | 991 mm | 983 mm | 997 mm | 1013 mm |
| Fork rake (offset) | — | — | — | — | — |
| Fork axle to crown | 360 mm | 360 mm | 360 mm | 360 mm | 360 mm |
| Trail | — | — | — | — | — |
| Standover | — | — | — | — | — |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
