Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S | M | L | XL | |
|---|---|---|---|---|
| Price (CAD) | $9,000 | $9,000 | $9,000 | $9,000 |
| Frame kit (g) | 1610 | 1610 | 1610 | 1610 |
| Stack | 547 mm | 569 mm | 589 mm | 609 mm |
| Reach | 367 mm | 377 mm | 385 mm | 393 mm |
| Stack / Reach | 1.49 | 1.51 | 1.53 | 1.55 |
| Head tube angle | 70.5° | 71.5° | 71.5° | 71.5° |
| Seat tube angle (effective) | 74° | 74° | 74° | 74° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 522 mm | 538 mm | 552 mm | 566 mm |
| Head tube length | 138 mm | 152 mm | 173 mm | 197 mm |
| Seat tube length | 463 mm | 491 mm | 510 mm | 537 mm |
| Bottom bracket drop | 79 mm | 79 mm | 79 mm | 76 mm |
| Bottom bracket height | — | — | — | — |
| Chainstay | 420 mm | 420 mm | 420 mm | 420 mm |
| Front center | 609 mm | 607 mm | 622 mm | 636 mm |
| Wheelbase | 1017 mm | 1015 mm | 1029 mm | 1045 mm |
| Fork rake (offset) | — | — | — | — |
| Fork axle to crown | 383 mm | 383 mm | 383 mm | 383 mm |
| Trail | — | — | — | — |
| Standover | — | — | — | — |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
