Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S | M | L | XL | |
|---|---|---|---|---|
| Price (CAD) | $9,000 | $9,000 | $9,000 | $9,000 |
| Frame kit (g) | 1700 | 1700 | 1700 | 1700 |
| Stack | 547 mm | 570 mm | 590 mm | 610 mm |
| Reach | 358 mm | 368 mm | 376 mm | 384 mm |
| Stack / Reach | 1.53 | 1.55 | 1.57 | 1.59 |
| Head tube angle | 69.1° | 70.5° | 71.5° | 72° |
| Seat tube angle (effective) | 73.5° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 529 mm | 547 mm | 561 mm | 575 mm |
| Head tube length | 142 mm | 158 mm | 175 mm | 196 mm |
| Seat tube length | 466 mm | 491 mm | 521 mm | 549 mm |
| Bottom bracket drop | 79 mm | 76 mm | 76 mm | 74 mm |
| Bottom bracket height | — | — | — | — |
| Chainstay | 437 mm | 437 mm | 437 mm | 437 mm |
| Front center | 620 mm | 612 mm | 617 mm | 626 mm |
| Wheelbase | 1044 mm | 1036 mm | 1040 mm | 1050 mm |
| Fork rake (offset) | — | — | — | — |
| Fork axle to crown | 387 mm | 387 mm | 387 mm | 387 mm |
| Trail | — | — | — | — |
| Standover | — | — | — | — |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
